Engine Bottom End – Crankshaft, crankcase, clutch, transmission

September 27, 2011
Part # # ←picture#………Description Price Applications
###### ### ############################# #### #################################
……… E N G I N E… S E A L S … …
106019 seal 06x15x4 80-85 Morini M101 shifter shaft
2810361 seal 10x16x4 86-89 Derbi shifter shaft
8228630 seal 12x18x3 76-86 Derbi shifter shaft
106021 seal 13x19x3 80-85 Morini M101 variator
19089 seal 15x21x4 74-80 Motobecane L&R crank
4790 seal 15x24x5 76-80 Minarelli pedal shaft
106003 seal 15x24x7 76-80 Morini countershaft
8228400 seal 15x30x7 76-86 Derbi countershaft
8235300 seal 16x24x4 76-89 Derbi L&R pedal shaft
106004 seal 16x24x5 76-80 Morini pedal shaft
19858 seal 16.5x23x3 76-80 Motobecane fork
6125230 seal 17x28x6 76-86 Derbi L&R crank
2500231 seal 17x30x7 86-89 Derbi L&R crank
4710 seal 17x35x8 76-80 Minarelli L&R crank
106001 seal 17x35x8 76-on Tomos/Morini/others L&R crank
106020 seal 19x24x3.8 80-85 Morini M101 variator
3129130 seal 20x30x7
1200341 seal 20x32x4 76-on Derbi wheels
… E N G I N E… B E A R I N G S…
metric ball bearings also used in wheels to remove a shield an awl pokes a hole
are for many machines besides mopeds then bends the shield to pluck it out
so they’re also sold by bearing suppliers
…………model….dimensions…style
bearing 608RS……08x22x07 1-R seal $8 Tomos 2sp trans cover front
…………………10mm…bearings………………
bearing 6900………10x22x06 open N/A
bearing 6000 ….…10x26x08 open $8 Tomos 2sp trans cover rear
bearing 6000Z……10x26x08 1-shield $8
bearing 6000ZZ …10x26x08 2-shield $8
bearing 16100……10x28x08 open $20 Puch 2sp trans cover rear
bearing 6200……..10x30x09 open $8
bearing 6200ZZ…10x30x09 2-shield $8
bearing 6200RS…10x30x09 1-R seal $12
bearing 6300………10x35x11 open N/A
…………………12mm…bearings………………
bearing 6901………12x24x06 open N/A
bearing 16001…….12x28x07 open N/A
bearing 6001……..12x28x08 open $8
bearing 6001ZZ… 12x28x08 2-shield $8
bearing 6001-2RS 12x28x08 2-R seal $9
bearing 16101ZZ..12x30x08 2-shld $30 Puch snowflake R wheel bearing upgrade
bearing 6201………12x32x10 open $10
bearing 6201ZZ …12x32x10 2-shield $10
bearing 6301………12x37x12 open N/A
…………………15mm…bearings………………
bearing 6902………15x28x07 open N/A
bearing 16002… 15x32x08 open N/A
bearing 6002… 15x32x09 open $8 Puch 2sp trans cover front
bearing 6002ZZ 15x32x09 2-shield $8
bearing 6202… 15x35x11 open $8 Sachs Vespa R&L
bearing 6202ZZ… 15x35x11 2-shield $8
bearing 6202-2RS 15x35x11 2-shield $8
bearing 6302… 15x42x13 open $10
bearing 6302QR 16x42x13 OS w/radius N/A Motobecane must cut crank to 6302
…………………17mm…bearings………………
bearing 6903-2RS 17x30x07 2-Rseal $15
bearing 16003… …17x35x08 open N/A
bearing L17……… 17x35x10 3-piece open N/A Puch 2sp left Tomos 75-85 Sears Allstate
bearing 6003… 17x35x10 open N/A
bearing 6203… 17x35x12 open $10 Tomos 86-later Minarelli Puch 1sp L others
bearing 6203ZZ 17x35x12 2-shield $10
bearing 6203NR 17x35x12 clip groove $12 Puch 1sp right crank
bearing 6303 17x47x14 open $10
…………………20mm…bearings………………
bearing 6004………20x42x12 open $12
bearing E20 ………20x47x12 3-piece open $30 Puch 2sp right crank
bearing 6204………20x47x14 open $15
bearing 6304………20x52x15 open N/A
…………………25mm…bearings………………
bearing 6005………25x47x12 open $15 Puch 2sp left driveshaft
…………………30mm…bearings………………
bearing 6006………30x55x13 open $18 Tomos left driveshaft
bearing 6006ZZ …30x55x13 2-shield $18 Tomos left driveshaft
